Mailbox

Mailbox adds a secure three-account mail workspace and integration layer to ProcessWire: IMAP folders and messages, SMTP delivery, OAuth, encrypted caching/indexing, PHP/REST/CLI access, AI-assisted reading, and controlled confirmation workflows.

It is made for ProcessWire sites that need email inside an editorial or operational workflow without turning the CMS into an unrestricted public webmail server.

Author: Maxim Semenov
Website: smnv.org
Email: maxim@smnv.org

If this project helps your work, consider supporting future development: GitHub Sponsors or smnv.org/sponsor.

What Mailbox Does

• Connects up to three IMAP/SMTP accounts and switches between them in the admin.
• Supports password/app-password accounts and Google/Microsoft OAuth2/XOAUTH2.
• Includes hosted-provider, control-panel, and open-source mail-server presets plus credential-free discovery.
• Lists all folders and up to 100 newest messages per page.
• Provides search, attachments, HTML/text/raw views, pagination, bulk actions, reply, and forward.
• Marks a visibly opened unread message Seen through a separate authenticated receipt; background/API reads remain read-only.
• Stores usernames, passwords, and OAuth tokens in a dedicated encrypted table.
• Keeps admin message cache and optional local index encrypted and account-bound.
• Provides permission-gated PHP, same-origin REST, and local CLI interfaces.
• Supports encrypted notifications, webhooks, IMAP IDLE, and an indexed-message hook.
• Adds controlled confirmation-link proposals with separate human approval and execution.
• Integrates optionally with Squad for summaries and reply drafts, and exposes feature-detected boundaries for Verk, Kontor, and Tickets.

Admin Area

Mailbox adds Setup > Mailbox with four workspaces:

• Mailbox — accounts, folders, search, message list, reader, actions, cache status, and diagnostics;
• Discover settings — review-only provider/DNS/autoconfig candidates without credentials or writes;
• Accounts — superuser management for the three account profiles;
• Runtime — bounded installation of the locked Webklex and PHPMailer packages into persistent site assets.

The interface follows ProcessWire AdminThemeUikit and mxmsmnv/pw-design-system, supports light/dark themes, a persistent collapsible sidebar, and responsive message tables.

Message Safety

Message HTML is never inserted directly into the admin page. It is server-sanitized and rendered in a sandboxed, credentialless, CSP-restricted iframe. Scripts, forms, frames, event handlers, active links, and remote images are blocked by default.

Remote HTTPS images and external HTTPS message links have separate disabled-by-default privacy acknowledgements. External links are limited to public hostnames on port 443 and open with noopener noreferrer plus layered no-referrer policy. The admin URL is not sent as Referer, but a destination may still observe the click, IP/browser characteristics, time, and tokens already contained in its own URL.

Attachments require a separate permission and are forced downloads with no-sniff/no-store headers, safe names/types, and decoded-size limits.

Accounts and Transports

Each account stores a non-secret connection profile in mailbox_accounts and an encrypted credential row in mailbox_credentials. Passwords and OAuth tokens are never rendered back into forms.

The Auto IMAP engine uses Webklex for hosted providers such as Gmail and can retain native PHP IMAP for compatible self-hosted servers. Webklex forces the Composer transport. Native PHP IMAP explicitly requires ext-imap. Every non-loopback connection requires TLS certificate validation.

Presets are editable starting points, not proof of reachability. Mailbox includes Gmail, Microsoft 365/Outlook, iCloud, Yahoo, Fastmail, Zoho, Proton Bridge, HestiaCP, VestaCP, Poste.io, iRedMail, CyberPanel, Mail-in-a-Box, Modoboa, cPanel, Plesk, DirectAdmin, Dovecot, Stalwart, and custom templates.

API, CLI, AI, and Integrations

The permission-gated PHP API starts with:

<?php namespace ProcessWire;

if(!$modules->isInstalled('Mailbox') || !$user->isLoggedin()) return;

/** @var Mailbox $mailbox */
$mailbox = $modules->get('Mailbox');
$api = $mailbox->api($user, 1);

if($api->canRead()) {
    $messages = $api->messages('INBOX', 1, 20);
}

The optional REST API is same-origin and session-only at /mailbox-api/v1/; it has no CORS or bearer-token mode. The local CLI is bin/mailbox and requires a trusted ProcessWire bootstrap. Sending, mutations, attachments, AI, and confirmations retain separate settings and permissions on every surface.

Squad integration sends only bounded agent-safe text and never lets AI send, approve, or execute automatically. Reply drafts require human review. Tickets can optionally consume the indexed-message hook without creating a hard dependency. Verk/Kontor approval adapters remain feature-detected and Mailbox retains authority over proposal state and permissions.

See API.md, EXAMPLES.md, and INTEGRATIONS.md for verified calls and contracts.

Permissions

• mailbox-view — admin mailbox workspace;
• mailbox-api — logged-in PHP/REST reader;
• mailbox-attachments — attachment bytes/text;
• mailbox-write — flags, moves, and deletion marking;
• mailbox-send — SMTP tests and delivery;
• mailbox-confirm-links — confirmation review and execution.

Installation alone enables none of the optional write, send, API, CLI, AI, webhook, attachment, remote-content, or confirmation capabilities.

Requirements

• ProcessWire 3.x with AdminThemeUikit;
• PHP 8.0.2 or newer;
• PHP JSON and sodium extensions;
• PHP cURL for discovery/OAuth/webhooks/confirmations;
• Composer for the locked Webklex 5.5.0 and PHPMailer 6.12.0 runtime;
• ext-imap only when an account explicitly selects the native engine.

Installation

1. Copy the Mailbox folder into /site/modules/.
2. In ProcessWire Admin, refresh modules and install Mailbox.
3. Open Modules > Mailbox and set a dedicated $config->mailboxSecret before storing production credentials.
4. Open Runtime and install the exact packages from composer.lock, or run composer install --no-dev --prefer-dist and let Mailbox migrate the runtime into site/assets/Mailbox/runtime/vendor.
5. Configure the primary account or open Accounts for additional mailboxes.
6. Test IMAP and SMTP independently before enabling actions or integrations.
7. Assign the minimum required permissions to non-superuser roles.

For nginx, deny direct HTTP access to /site/assets/Mailbox/runtime/. Apache/IIS deny files are written by the runtime installer.

Admin Interface Language

The Mailbox admin and configuration interface ships with ready-made translations for German, French, Italian, Spanish, and Dutch, following ProcessWire's standard module-translation mechanism (languages/*.csv).

To install one: Setup > Modules > Mailbox > install translations (available when Language Support and a non-default language are installed), select the CSV for each target language, and submit. ProcessWire then uses the current administrator's language automatically.

Requires ProcessWire's core Language Support module.

Security and Operations

Use a dedicated $config->mailboxSecret; do not rotate it in place without a tested re-encryption and rollback plan. Treat the database and matching config.php backup as one security unit. OAuth client secrets and webhook signing keys belong in config.php, Vault, or KMS—not module settings.

Uninstall drops account, credential, encrypted cache/index, sync, job, and notification tables. Persistent runtime packages and confirmation-state files require an explicit retention/removal decision. Back up required settings and matching keys before uninstall.

See SECURITY.md for the complete threat model and operational boundaries.

Documentation

• API.md — public methods, REST resources, hooks, limits, and compatibility;
• EXAMPLES.md — known-good PHP, REST, CLI, OAuth, and integration examples;
• INTEGRATIONS.md — Verk, Kontor, Squad, and Tickets contracts;
• AGENTS.md — Olivia/AI-agent guidance for recommendation, site architecture, approval, and rollback;
• SECURITY.md — security model and residual risks;
• CHANGELOG.md — release notes.

Author

Maxim Semenov
smnv.org
maxim@smnv.org

License

MIT
