FieldtypeFileB2 - Store Files on Backblaze B2 Cloud Storage

FieldtypeFileB2 for ProcessWire

Store and serve files directly from Backblaze B2 Cloud Storage in ProcessWire. Now supports files up to 700MB with automatic chunked uploads.

Features

• Direct B2 Upload - Files upload directly to Backblaze B2
• Large Files Support - Up to 700MB with automatic chunked upload
• ⚡ Smart Upload - Auto-switches between standard and chunked methods
• Cost Effective - $6/TB/month (5x cheaper than AWS S3)
• Custom Domain Support - Use your own CDN domain
• ☁️ Cloudflare Integration - Free bandwidth via Bandwidth Alliance
• Public & Private Buckets - Flexible access control
• Multiple Files - Support for repeater fields with multiple files
• Perfect for Video - Tested with Plyr, Video.js and other players

Requirements

• ProcessWire 3.x
• PHP 7.4+ (8.3 recommended)
• cURL extension enabled
• Backblaze B2 Account
• For files >100MB: Properly configured Nginx/PHP timeouts

Installation

1. Download and extract to /site/modules/FieldtypeFileB2/
2. Go to Modules → Refresh
3. Install FieldtypeFileB2

Configuration

1. Create Backblaze B2 Account

1. Sign up at backblaze.com
2. Enable B2 Cloud Storage
3. Create a bucket (Public or Private)
4. Generate Application Key

2. Module Configuration

Setup → Modules → Configure → InputfieldFileB2

Backblaze Key ID: [Your Key ID]
Backblaze Application Key: [Your Application Key]
Bucket Name: your-bucket-name
Bucket ID: [Your Bucket ID]
Bucket Type: Public (or Private)
✅ Use SSL
❌ Store files locally (uncheck!)
Cache-Control max-age: 86400 (24 hours)

3. Create Field

1. Setup → Fields → Add New Field
2. Type: FieldtypeFileB2
3. Name: b2_video (or any name)
4. Add to your template

4. Web Server Optimization (CRITICAL for files >50MB)

PHP Settings (CloudPanel)

Sites → Your Site → PHP Settings:

PHP Version: 8.3
memory_limit: 512 MB
max_execution_time: 1800 (30 minutes)
max_input_time: 1800
post_max_size: 2 GB
upload_max_filesize: 2 GB
max_input_vars: 10000

Additional Configuration Directives:

date.timezone=UTC;
display_errors=off;
max_execution_time=1800;
max_input_time=1800;

Nginx Configuration (CloudPanel)

Sites → Your Site → Vhost → Edit:

Add these lines to BOTH server blocks (port 80/443 AND port 8080):

server {
  # ... existing config ...

  # CRITICAL: File upload limits
  client_max_body_size 2048M;
  client_body_timeout 1800s;

  # ... rest of config ...
}

server {
  listen 8080;
  # ... existing config ...

  # CRITICAL: File upload limits
  client_max_body_size 2048M;
  client_body_timeout 1800s;

  location ~ \.php$ {
    # ... existing config ...

    # CRITICAL: PHP-FPM timeouts
    fastcgi_read_timeout 1800;
    fastcgi_send_timeout 1800;
  }
}

After editing:

sudo nginx -t          # Test config
sudo systemctl reload nginx

5. Optional: Custom Domain with Cloudflare

For free bandwidth and faster delivery:

A. DNS Setup

Add CNAME record:

Type: CNAME
Name: cdn
Value: f005.backblazeb2.com (use your region)
Proxy: Enabled (orange cloud)

B. Cloudflare Transform Rule

Rules → Transform Rules → Create URL Rewrite Rule:

Rule name: B2 CDN Path Rewrite

If incoming requests match:
  Field: Hostname
  Operator: equals
  Value: cdn.yourdomain.com

Then rewrite the path:
  Dynamic: concat("/file/YOUR-BUCKET-NAME", http.request.uri.path)

C. Enable Custom Domain in Module

✅ Use Custom Domain
Custom Domain: cdn.yourdomain.com

How It Works

The module automatically chooses the best upload method:

Small Files (< 50MB)

Standard Upload:
1. Browser → Server (shows progress)
2. Server → B2 in one request
3. Success!

Large Files (≥ 50MB)

Chunked Upload:
1. Browser → Server (shows progress)
2. Server → B2 in 10MB chunks:
   - Chunk 1/50 (10MB)
   - Chunk 2/50 (10MB)
   - ... continues ...
   - Chunk 50/50 (10MB)
3. B2 assembles file
4. Success!

Benefits of Chunked Upload:

• ✅ Lower memory usage (reads 10MB at a time)
• ✅ More reliable for large files
• ✅ Can retry individual chunks if they fail
• ✅ Works around server limits

Usage Examples

Basic Usage

<?php namespace ProcessWire;

// Single file
<?php if($page->b2_video): ?>
<video controls>
    <source src="<?= $page->b2_video->url ?>" type="video/mp4">
</video>
<?php endif; ?>

// Multiple files
<?php foreach($page->b2_video as $video): ?>
<video controls>
    <source src="<?= $video->url ?>" type="video/mp4">
</video>
<?php endforeach; ?>

With Custom Domain (b2url property)

<?php foreach($page->b2_video as $video): ?>
<video controls>
    <source src="<?= $video->b2url ?>" type="video/mp4">
</video>
<?php endforeach; ?>

With Plyr Player

<link rel="stylesheet" href="https://cdn.plyr.io/3.7.8/plyr.css">

<?php foreach($page->b2_video as $video): ?>
<video class="plyr-video" playsinline controls>
    <source src="<?= $video->b2url ?>" type="video/mp4">
</video>
<?php endforeach; ?>

<script src="https://cdn.plyr.io/3.7.8/plyr.polyfilled.js"></script>
<script>
    Plyr.setup('.plyr-video', {
        controls: ['play-large', 'play', 'progress', 'current-time',
                   'mute', 'volume', 'fullscreen']
    });
</script>

In Repeater Fields

<?php foreach($page->videos as $item): ?>
    <h3><?= $item->title ?></h3>

    <?php foreach($item->b2_video as $video): ?>
    <video controls>
        <source src="<?= $video->b2url ?>" type="video/mp4">
    </video>
    <?php endforeach; ?>
<?php endforeach; ?>

File Size Limits

*Times assume 10 Mbps upload speed and properly configured server

Pricing Comparison

Backblaze B2 + Cloudflare

• Storage: $6/TB/month
• Bandwidth: $0 (free via Cloudflare)
• Transactions: Free (first 2,500/day)

Example: 500 GB storage + 5 TB bandwidth = $3/month

AWS S3 (for comparison)

• Storage: $23/TB/month
• Bandwidth: $90/TB
• Transactions: $0.005 per 1,000

Same usage: 500 GB storage + 5 TB bandwidth = $461.50/month

You save 99% on bandwidth with Cloudflare!

Troubleshooting

Files return 404

Cause: Files not uploaded to B2 or localStorage enabled

Solution:

1. Check if localStorage is disabled in module settings
2. Verify bucket is Public (or CORS configured for Private)
3. Check ProcessWire logs for upload errors
4. Confirm files exist in B2 bucket

Upload freezes or times out

Cause: Insufficient server timeouts

Solution:

1. Verify Nginx timeouts are set (see configuration above)
2. Verify PHP timeouts are set (see configuration above)
3. Check server logs:

tail -f /var/log/nginx/error.log
tail -f /var/log/php8.3-fpm.log

Large files (>100MB) fail to upload

Cause: Server resource limits or network issues

Solution:

1. Increase timeouts to 30 minutes (1800s)
2. Check PHP memory: Should be 512MB minimum
3. Test network speed: Upload may take time
4. Check logs for specific error:

tail -100 /var/log/nginx/error.log

Video not playing

Cause: Codec compatibility or CORS issues

Solution:

1. Verify MP4 codec compatibility (H.264 video, AAC audio)
2. Check CORS configuration (if private bucket)
3. Confirm file uploaded with correct Content-Type
4. Test direct B2 URL in browser

502 Bad Gateway or 504 Gateway Timeout

Cause: Nginx or PHP-FPM timeout

Solution:

# In Nginx vhost:
fastcgi_read_timeout 1800;
client_body_timeout 1800s;

# In PHP settings:
max_execution_time = 1800

Memory exhausted error

Cause: File too large for available PHP memory

Solution:

1. Increase PHP memory_limit to 512MB
2. Module uses chunked reading (10MB at time) so shouldn't happen
3. If still occurs, check for other memory-intensive plugins

CORS Configuration

For cross-domain requests or private buckets:

[
  {
    "corsRuleName": "downloadFromAnyOrigin",
    "allowedOrigins": ["https://yourdomain.com"],
    "allowedOperations": ["b2_download_file_by_name"],
    "allowedHeaders": ["*"],
    "exposeHeaders": ["*"],
    "maxAgeSeconds": 3600
  }
]

Best Practices

For Production Use

1. Use Custom Domain with Cloudflare for free bandwidth
2. Enable Cloudflare Caching for faster delivery
3. Set appropriate Cache-Control headers (24-48 hours for videos)
4. Use Public buckets for simpler setup (unless security required)
5. Disable localStorage to use B2 storage
6. Monitor B2 costs in your Backblaze dashboard

For Large Files (>100MB)

1. Increase server timeouts to 30 minutes (1800s)
2. Test with smaller files first to verify configuration
3. Monitor logs during upload to catch issues early
4. Warn users about upload time for large files
5. Consider file size limits in your UI

Cloudflare Caching Optimization

Page Rules:

URL: cdn.yourdomain.com/*
Settings:
  - Cache Level: Cache Everything
  - Edge Cache TTL: 1 month
  - Browser Cache TTL: 4 hours

This will:

• Reduce B2 API calls to near zero
• Speed up video delivery worldwide
• Maximize free bandwidth usage

Technical Details

Chunked Upload Specs

• Chunk Size: 10MB
• Threshold: Files ≥ 50MB use chunked upload
• Max File Size: ~970GB (theoretical B2 limit: 10,000 chunks × 100MB)
• Current Practical Limit: 700MB (tested)

B2 API Endpoints Used

• b2_authorize_account - Authentication
• b2_get_upload_url - Standard uploads
• b2_start_large_file - Start chunked upload
• b2_get_upload_part_url - Get URL for each chunk
• b2_finish_large_file - Complete chunked upload
• b2_list_file_names - File listing (for delete)
• b2_delete_file_version - Delete files

Monitoring & Logs

Check Upload Progress

ProcessWire logs show detailed upload progress:

Setup → Logs → messages

Standard upload:
"Starting standard upload for 45.23MB file"

Chunked upload:
"Starting chunked upload for 256.78MB file"
"Uploading 26 chunks of 10MB each"
"Uploaded chunk 1/26"
"Uploaded chunk 2/26"
...
"Successfully uploaded 26 chunks"

Server Logs

# Nginx errors
tail -f /var/log/nginx/error.log

# PHP-FPM errors
tail -f /var/log/php8.3-fpm.log

# Follow both simultaneously
tail -f /var/log/nginx/error.log /var/log/php8.3-fpm.log

Upgrade from Previous Versions

See CHANGELOG.md for version history and upgrade notes.

Quick Upgrade

# Backup current module
cp -r /site/modules/FieldtypeFileB2 /site/modules/FieldtypeFileB2.backup

# Copy new files
cp -r FieldtypeFileB2/* /site/modules/FieldtypeFileB2/

# Refresh modules in ProcessWire
# Modules → Refresh

Important: Version 10+ requires updated Nginx/PHP settings for large files.

License

MIT License - feel free to use commercially

Credits

Developed for video hosting on lqrs.com

Built with ProcessWire CMS and Backblaze B2 API

Support

For issues and feature requests:

• GitHub Issues: [your-repo-url]
• ProcessWire Forum: [forum-link]

Changelog

See CHANGELOG.md for detailed version history.

Latest Changes (v1.0)

• ✅ Added chunked upload support for files ≥ 50MB
• ✅ Tested with files up to 700MB
• ✅ Improved logging for upload progress
• ✅ Automatic method selection (standard vs chunked)
• ✅ Better error handling and recovery
• ✅ Comprehensive documentation for large files

Note: This module is under active development. Always test with non-critical data first.
