Compass

Heatmap analytics for ProcessWire. Tracks where visitors click, how far they scroll, rage clicks, and mouse movement — visualised as an interactive heatmap directly in the admin.

Features

• Click heatmap — see exactly where visitors click on each page
• Mouse movement — thermal map of cursor paths
• Rage clicks — detect frustration: 3+ clicks in the same spot within 700ms
• Scroll depth — how far visitors scroll before leaving
• Per-page viewer — browse any tracked page with iframe + canvas overlay
• Date range filter — last 7 / 30 / 90 days or full year
• Device filter — compare desktop, mobile and tablet behaviour
• Device stats — see traffic split in the admin viewer
• Export PNG — save the heatmap layer as an image
• Dark mode — uses --pw-* CSS variables, works with AdminThemeUikit automatically
• Native Analytics integration — adds an optional Compass tab when Native Analytics supports hookable dashboard tabs
• Zero external requests — all data stays on your server

Requirements

• ProcessWire 3.0.0+
• PHP 8.0+

Installation

1. Download or clone this repository into /site/modules/Compass/
2. In the ProcessWire admin go to Modules → Refresh, then find Compass and click Install
3. The module creates the compass_events table automatically on install

File structure

Compass/
├── Compass.module.php           # Core module — autoload, hooks, DB, config
├── CompassAPI.php               # AJAX endpoints: /compass-track and /compass-data
├── ProcessCompass.module.php    # Admin UI — page list + iframe heatmap viewer
├── js/
│   ├── tracker.js               # Frontend tracker (clicks, scroll, rage, movement)
│   └── viewer.js                # Admin viewer (iframe + canvas overlay)
├── css/
│   └── viewer.css               # Admin UI styles
└── lib/
    └── heatmap.min.js           # heatmap.js v2 (MIT) — place manually, see Installation

How it works

Tracking

Once installed, Compass automatically injects a small tracker script (tracker.js, ~3kb minified) into every frontend page. The script collects events and sends them in batches to the site-root compass-track endpoint using navigator.sendBeacon (with fetch as fallback). No page load performance impact.

Events are stored in a single MySQL table compass_events.

Viewing

Go to Setup → Compass in the admin. Select any page from the left sidebar — its URL loads in an iframe on the right, with the heatmap rendered as a canvas overlay. Switch between event types and date ranges using the toolbar.

If Native Analytics is installed and exposes hookable dashboard tabs, Compass also appears as a tab inside its dashboard. This integration is optional; Compass remains fully usable from Setup → Compass without Native Analytics.

Configuration

Go to Modules → Compass → Settings.

Privacy & GDPR

Compass does not collect:

• IP addresses
• User agents
• Personal identifiers

Each visitor is assigned an anonymous session cookie (compass_sid) — a random 32-character hex string with no link to user identity. The cookie is HttpOnly, SameSite=Lax, and Secure when the site runs over HTTPS. It expires after 1 year.

Depending on your jurisdiction you may still need to disclose heatmap tracking in your privacy policy.

Rate limiting

The /compass-track endpoint limits each session to 300 events per 60 seconds and rejects oversized batches above 300 events per request. Requests exceeding the rolling event limit return HTTP 429; oversized payloads return HTTP 413. Adjust the constants in Compass.module.php if needed:

const RATE_LIMIT_WINDOW      = 60;   // seconds
const RATE_LIMIT_MAX         = 300;  // events per window
const MAX_EVENTS_PER_REQUEST = 300;

Security

• /compass-track — public endpoint, accepts POST only. Cross-origin requests (mismatched Origin header) are rejected with HTTP 403 to prevent third-party sites from polluting your analytics data.
• /compass-data — restricted to logged-in superusers. Every request must include a valid ProcessWire CSRF token.
• X-Frame-Options — Compass sets X-Frame-Options: SAMEORIGIN on frontend pages when a superuser is browsing, allowing the iframe viewer to display them. Admin pages and regular visitor responses are unaffected.

License

MIT © Maxim Semenov — maxim@smnv.org

If this project helps your work, consider supporting future development: GitHub Sponsors or smnv.org/sponsor.
