Atlas adds a lightweight retrieval-augmented generation (RAG) store to ProcessWire: it embeds text, keeps vectors in ProcessWire's configured SQL database and returns the most relevant entries for a query. A local lexicalSearch() first pass is also available for latency-sensitive integrations that only need semantic retrieval when literal matches are weak.

It is made for small and medium knowledge bases where semantic search and grounded AI responses should live inside ProcessWire without requiring pgvector, Qdrant or another external vector service.
Author: Maxim Semenov
Website: smnv.org
Email: maxim@smnv.org
If this project helps your work, consider supporting future development: GitHub Sponsors or smnv.org/sponsor.
What Atlas Does
- Produces provider-independent embeddings through Squad.
- Organizes entries into independent collections.
- Splits long documents into paragraph- and sentence-aware chunks.
- Searches by cosine similarity with optional literal keyword boosting.
- Supports metadata filtering and Maximal Marginal Relevance (MMR) diversification.
- Keeps each collection consistent with one embedding model and vector dimension.
- Atomically replaces chunked documents and full-site indexes, preserving the previous data if embedding fails.
- Builds domain-neutral page documents from core fields and optional ProFields, with labelled nested content and absolute media URLs.
- Exposes ProcessWire hooks for custom field projections, external document sources and indexing notifications.
- Stores everything in one ProcessWire database table with no additional service dependency.
- Provides a ProcessWire admin area for browsing, searching, adding, deleting and rebuilding indexed content.
Atlas is intended for collections up to roughly 10,000 entries. Larger corpora should use a dedicated vector database behind a custom storage implementation.
Admin Area
The optional ProcessAtlas module adds a responsive Setup > Atlas workspace with dedicated Overview, Collections, Search and Reindex views, where site editors can:
- check embedding-provider readiness and index totals;
- browse collections and their statistics;
- inspect paginated entries, structured content and source metadata;
- add individual entries and create collections;
- search with semantic similarity, keyword boosting and MMR;
- delete entries or clear a collection;
- add missing public pages without rebuilding existing entries, or explicitly rebuild a selection with live batched progress, retry and cancellation.
Indexing large selections
Use Reindex → Add missing pages (the default) to extend an existing collection. Atlas checks actual stored page refs first, skips existing documents, and embeds only absent pages or documents whose saved chunk count proves they are incomplete. Legacy documents without saved chunk counts are treated as present. This mode deliberately does not refresh changed text; choose Rebuild selection — reuse unchanged pages for that. A forced rebuild embeds every selected document.
A run checks at most 10,000 selected pages, in ascending page-ID order. To cover the next portion, enter the displayed last completed page ID in Start after page ID. Leave it at zero to revisit the beginning and fill missing documents. The limit bounds the pages checked, not the number newly added. Rebuild modes replace the collection with that selection and can remove other entries; add-missing preserves them.
Keep the tab open. Closing it pauses the browser-driven job; reopen Reindex in the same authenticated session to continue. On provider/storage errors, use Try again to resume the saved checkpoint. Add-missing commits each completed document; cancelling preserves those additions. A rebuild keeps the previous collection until promotion. Session expiry loses the browser job; a fresh add-missing run can still skip documents already committed. Do not run overlapping rebuilds against the same collection.
Run php tests/run.php and php tests/reindex.php (the latter needs PDO SQLite) for regression checks without contacting an embedding provider.
PHP API
$atlas = $modules->get('Atlas');
$atlas->add(
'faq',
'password-reset',
'Use the password reset form on the account page.',
['url' => '/account/reset']
);
$hits = $atlas->search('faq', 'I forgot my password', 3);
Atlas also provides batch insertion, document chunking, metadata filters, hybrid keyword search, MMR diversification, collection statistics and chunk-aware deletion. See the API documentation for the complete method and option reference.
Reindex hooks
The default adapter is domain-neutral: it indexes labelled values from common ProcessWire fields (including ProFields Table, Combo, Textareas, Multiplier and Repeater Matrix), adds hierarchy context to title-only pages, ignores presentation fields, and records template/path metadata. Optional field modules are detected through public APIs and are not Atlas dependencies. Other modules can refine one field through ProcessAtlas::buildPageFieldText, or replace/extend the complete document through ProcessAtlas::buildPageDocument without changing Atlas core. For example:
$wire->addHookAfter('ProcessAtlas::buildPageDocument', function(HookEvent $event) {
$page = $event->arguments(0);
$document = $event->return;
$document['text'] .= "\n" . (string) $page->summary;
$document['meta']['source_app'] = 'catalog';
$event->return = $document;
});
ProcessAtlas::reindexReady can add documents from another application directly to the internal staging collection before it is promoted. Success notifications are available through ProcessAtlas::pageIndexed and ProcessAtlas::collectionReindexed. See DOCUMENTATION.md for the contracts and a complete external-source example.
Requirements
- ProcessWire 3.0.200 or newer.
- Squad, installed and configured with an embedding-capable provider.
- MySQL/MariaDB, SQLite, or PostgreSQL through ProcessWire's database layer.
Atlas 1.2.3 is the current release. ProcessWire represents this module version internally as 123.
PocketWire
Atlas opts into PocketWire through a status-only provider guarded by the
current actor and atlas-admin. It does not enumerate collection names or
sizes, return indexed text or metadata, inspect Squad/provider configuration,
perform an embedding request, or expose indexing, reindexing and deletion
actions. Collection diagnostics remain in Atlas's existing admin/API surfaces.
Installation
- Copy the
Atlas folder into /site/modules/. - In ProcessWire Admin, refresh modules.
- Install
Atlas; this creates the atlas_vectors table. - Optionally install
ProcessAtlas to add Setup > Atlas. - Configure an embedding provider in Squad before indexing or searching.
Documentation
See DOCUMENTATION.md for the complete PHP API, search options, result format, schema and operating limits.
See CHANGELOG.md for the release notes.
Run the dependency-free algorithm and security smoke tests with:
php tests/run.php
Database, ProcessWire and Squad integration should additionally be tested in a non-production ProcessWire installation.
Author
Maxim Semenov
smnv.org
maxim@smnv.org
License
MIT
